Động cơ Servo Yaskawa SGM7J

Posted on by admin
Động cơ Servo Yaskawa SGM7J
02
Th11

Động cơ Servo Yaskawa SGM7J

 Video Flyer Brochure Tech Supplement Core Manuals Configurator Instructions

Động cơ Servo Yaskawa SGM7J 200V Input (24-bit encoder)

Part Number
Rated Output
Options
SGM7J-A5A7D6150WNo Options
SGM7J-A5A7D6C50W24V Brake
SGM7J-A5A7D6E50W24V Brake, Shaft Seal
SGM7J-A5A7D6S50WShaft Seal
SGM7J-01A7D61100WNo Options
SGM7J-01A7D6C100W24V Brake
SGM7J-01A7D6E100W24V Brake, Shaft Seal
SGM7J-01A7D6S100WShaft Seal
SGM7J-C2A7D61150WNo Options
SGM7J-C2A7D6C150W24V Brake
SGM7J-C2A7D6E150W24V Brake, Shaft Seal
SGM7J-C2A7D6S150WShaft Seal
SGM7J-02A7D61200WNo Options
SGM7J-02A7D6C200W24V Brake
SGM7J-02A7D6E200W24V Brake, Shaft Seal
SGM7J-02A7D6S200WShaft Seal
SGM7J-04A7D61400WNo Options
SGM7J-04A7D6C400W24V Brake
SGM7J-04A7D6E400W24V Brake, Shaft Seal
SGM7J-04A7D6S400WShaft Seal
SGM7J-06A7D61600WNo Options
SGM7J-06A7D6C600W24V Brake
SGM7J-06A7D6E600W24V Brake, Shaft Seal
SGM7J-06A7D6S600WShaft Seal
SGM7J-08A7D61750WNo Options
SGM7J-08A7D6C750W24V Brake
SGM7J-08A7D6E750W24V Brake, Shaft Seal
SGM7J-08A7D6S750WShaft Seal

Động cơ Servo Yaskawa SGM7J 400V Input (24-bit encoder)

Part Number
Rated Output
Options
SGM7J-02D7F61200WNo Options
SGM7J-02D7F6C200W24V Brake
SGM7J-02D7F6E200W24V Brake, Shaft Seal
SGM7J-02D7F6S200WShaft Seal
SGM7J-04D7F61400WNo Options
SGM7J-04D7F6C400W24V Brake
SGM7J-04D7F6E400W24V Brake, Shaft Seal
SGM7J-04D7F6S400WShaft Seal
SGM7J-08D7F61750WNo Options
SGM7J-08D7F6C750W24V Brake
SGM7J-08D7F6E750W24V Brake, Shaft Seal
SGM7J-08D7F6S750WShaft Seal
SGM7J-15D7F611.5kWNo Options
SGM7J-15D7F6C1.5kW24V Brake
SGM7J-15D7F6E1.5kW24V Brake, Shaft Seal
SGM7J-15D7F6S1.5kWShaft Seal

50W – 1.5kW, Medium Inertia

The SGM7J was designed to maximize responsiveness in applications where precise load matching is of critical importance. This family of medium inertia rotary servo motors was created with low capacity applications in mind, yet can respond with rated speeds to 3000 rpm and torque ratings up to 2.39 N-m (21 in-lb) when an application requires it. 24-bit encoder resolution maintains industry-leading positional accuracy in any operating condition.

Features Highlights:

  • 24-bit encoder resolution
  • More compact than other motors with similar ratings, for a better fit in tight spaces
  • Completely compatible with Sigma-7 servos
  • Neodymium iron boron permanent magnets with a high flux density reduce rotor size
  • Advanced magnetic circuitry and optimum winding geometry deliver very low cogging torque
  • Safety rated at  SIL 3 (IEC 61508)
  • IP67 rated for resistance to dust, water washdown
  • Functions in temperatures above 60oC, altitudes above 2000 ft.
  • Peak acceleration torque up to 300% of rated torque
  • Peak torque can be maintained for up to three seconds
  • Rated speed of 3,000 rpm, max speed of 6,000 rpm
  • Runs 20% cooler than previous generation products
  • Holding Brake and Shaft Seal option available
